Eco Budget Dispensing
Cost‑effective silicone dispensing system offering precise metering, flexible tank configurations, and reliable temperature control for industrial production.
Choose Variant
Economical configuration with 2 tank system, basic metering pumps, and manual ratio adjustment — ideal for low to medium volume production.
₹1,20,000.00–₹1,50,000.00/ per-unit
MOQ: 1 unitLead time: 4–6 weeks
Key Features
- •2/3/4 Tank System for flexible material supply
- •Optional HMI & PLC for process control and automation
- •Single or Multi‑Head Dispensing
- •Precise Metering Pumps for accurate dosing
- •Variable Flow Rate from 1 g/sec to 70 g/sec
- •Variable Ratio Machine suitable for material changeover
- •Non‑Drip Dispensing Gun for clean cut‑off
- •Precise Temperature Control for consistent material properties
Benefits
- Accurate silicone dosing reduces waste and improves product consistency
- Flexible configurations adapt to different production volumes
- Cleaner production with non‑drip dispensing gun
- Improved process control and repeatability with optional HMI & PLC
Applications
Electronics potting and sealingAutomotive gasketing and bondingLED and lighting assemblyMedical device sealing and encapsulationGeneral industrial sealing and adhesive dispensing
Technical Specifications
- Tank Configuration
- 2 tank system
- Flow Rate
- 1 g/sec – 40 g/sec
- Pump Options
- Standard metering pumps
- Dispensing Heads
- Single or multi‑head
- Ratio Control
- Manual adjustment
- Dispense Gun
- Non‑drip gun with adjustable cut‑off
- Temperature Control
- Precise monitoring and PID control
- Control Interface
- Basic control panel
- Power
- 110–240V AC
- Weight
- Approx. 40–60 kg (model dependent)
- Footprint
- Approx. 650 × 550 × 1200 mm
Technical specifications available on request. Custom configurations can be developed as per material viscosity and production requirements.
